What Is Bitumen Sprayer?

Bitumen sprayers are truck-mounted or trailer-mounted vehicles especially utilized to distribute bitumen on the pavement for road building and maintenance. It is also known as bitumen distributor. A typical bitumen sprayer is comprised of truck chassis, heated storage tank, pressured spraying system, PTO, and control system.

The price range of bitumen sprayer trucks is between $45,000 and $200,000. The techniques to make bitumen sprayers ensure high efficiency of sprinkling and application on large areas with superior quality. Other than bitumen, bitumen emulsion can also be sprayed by these bitumen distributors. In addition to truck-mounted ones, the separate upper main structures are also provided on demand if you need them.

Bitumen Sprayers For Sale

Brand New Bitumen Sprayers For Sale

intelligent Asphalt Distributor Truck LY5110GLQ for sale

Intelligent Bitumen Sprayer Truck LY5110GLQ

Serial Number: LRC51SP-1455
Model: LY5110GLQ
Chassis Brand: HOWO 4 × 2
Tank Volume: 5.5m³
Spray Bar Width: Max. 6,000mm(unfolding)
Condition: Brand new
Shipment Container
>Bitumen Sprayer LY5040GLQ

Bitumen Sprayer LY5040GLQ

Serial Number: LRC51SP-1468
Model: LY5040GLQ
Chassis Brand: HOWO 4 × 2
Tank Volume: 4m³
Spray Bar Width: 4,500mm / 6,000mm
Condition: Brand new
Shipment Container
Asphalt Sprayer LY5240GLQ

Asphalt Sprayer LY5240GLQ

Serial Number: LRC51SP-1480
Model: LY5240GLQ
Chassis Brand: HOWO 4 × 2
Tank Volume: 7m³
Spray Bar Width: Max. 6,000mm
Condition: Brand new
Shipment RORO
brand new Bitumen Distributor Truck With Max.6m Spray Bar for sale

Bitumen Distributor Truck With Max.6m Spray Bar

Serial Number: LRC51SP-1480
Model: LY5250GLQ
Chassis Brand: HOWO 4 × 2
Tank Volume: 8m³
Spray Bar Width: Max. 6,000mm
Condition: Brand new
Shipment RORO
bitumen Sprayer With 6m³ Tank

Bitumen Sprayer With 6m³ Tank

Serial Number: LRC51SP-1460
Model: LY5120GLQ
Chassis Brand: HOWO 4 × 2
Tank Volume: 6m³
Spray Bar Width: 4,500mm / 6,000mm
Condition: Brand new
Shipment RORO
new Bitumen Distributor LY5250GLQ for sale

Bitumen Distributor LY5250GLQ

Serial Number: LRC51SP-1480
Model: LY5250GLQ
Chassis Brand: HOWO / DONGFENG 6 × 4
Asphalt Tank Volume: 12m³
Spray Bar Width: Max. 7,200mm
Condition: Brand new
Shipment RORO

Liaoyuan Machinery has been engaged in the design, manufacture, and sales of bitumen sprayers since its foundation. Proven quality and competitive prices win clients' trust around the world. To date, our bitumen sprayer trucks have been sold and exported to 40 countries, such as Australia, Sri Lanka, UK, Brisbane, South Africa, Europe, India, Perth, Victoria, Kenya, New Zealand, Texas, Indonesia, Saudi Arabia, Iraq, Uzbekistan, Kazakhstan, Russia, Ethiopia, etc.

How Does A Bitumen Sprayer Work?

The Working Video Of Bitumen Sprayer Truck

1. Add the bitumen required, start the heating system to keep it warm via the circulation of heat transfer oil.
2. Calculate the speed of the vehicle and the rotating speed of the bitumen pump according to the amount of spraying. Then do some simulation operations.
3. Let Bitumen pumps and bitumen pipelines work in small circulation.
4. Set spray width and bitumen pump rotating speed. Then open the sprayer frame and raise it to a suitable height.
5. Transfer the bitumen system from small circulation to large circulation
6. Start spraying, the bitumen will be sprayed from the frame; turn off the spraying master control when the work area is completed.
7. Close the sprinkler frame, and clean the pipeline.
