Planetary Concrete Mixer (MP250-MP3000)



Planetary Concrete Mixer (MP250-MP3000)

  • Model: MP250 ~ MP3000
  • Leave Message

    Product Parameters
    Model MP250 MP330 MP500 MP750 MP1000 MP1500 MP2000 MP2500 MP3000
    Discharge volume (L) 250 330 500 750 1000 1500 2000 2500 3000
    Charging volume (L) 375 500 750 1125 1500 2250 3000 3750 4500
    Mixing drum diameter (mm) 1300 1540 1900 2192 2496 2796 3100 3400 3400
    Mixing motor power(kW) 11 15 18.5 30 37 55 75 90 110
    Discharging power(kW) 2.2 2.2 2.2 2.2 3 3 4 4 4
    Planet/paddle 1/2 1/2 1/2 1/3 2/4 2/4 3/6 3/6 3/9
    Side scraper 1 1 1 1 1 1 1 1 1
    Bottom scraper 1 1 1 1 1 1 2 2 2
    Weight(kg) 1200 1700 2000 3500 6000 7000 8500 10500 11000
    Dimension (L*W*H) 1570*
    1480
    *1750
    1862*
    1850
    *1855
    2220*
    2071
    *1880
    2581*
    2336
    *2195
    2891*
    2602
    *2217
    3223*
    2902
    *2425
    3625*
    3230
    *2630
    2893*
    3550
    *2695
    3893*
    3550
    *2975
    Main Features

    1. These concrete mixers are the kind of gravity stabilized two-cone reverse tilting concrete mixer, the mixing roller is driven by the gear, when it works, positive rotating show that the machine is stirring, and it will discharging when reversing. This mixer can stir plastic concrete and semirigid /hard concrete. It applies for construction site, road, bridge projects and all kinds of concrete component factory.
    2. The series of mixers are designed and manufactured according to Concrete Mixer Technological Conditions GB/T9142-2000; it is an advanced machine which has reasonable structure, high productivity, good mixing quality, graceful outline and convenient move, etc.
    3. The series of mixers are used as a single machine, it can form a simple mixing plant when it is combined with batching machine. The types also are moveable.
    4. The concrete mixers are bipyramid type and self-reverse mixers, concrete is mixed by drum rotating.
    5. The mixing drum is driven by gear set.
    6. Install 2 types for the mixer moving, electric motor for power supply.
