Technical Parameters

HZS series hopper lift concrete batching plant, belongs to compulsory and high efficiency equipment, it can produce various kinds of concrete including quaking concrete and hard concrete, with high productive efficiency, it is widely used in medium scale building works, road and bridge works and concrete products prefabricating plants, and is an ideal equipment to produce commercial used concrete. The main machine of this series use JS series double shaft compulsory mixer, it can mix concrete evenly, with a short period of mixing, long life wearing parts, it can be operated and maintained conveniently, it used control technology with newest design concept, for example: electric weighing,computer control, and digital display, etc., electric weighing has been equipped with buffer device and auto compensation function and the measure precision is high. Equipped with maintenance sidewalk, it is the ideal selection for the construction units to produce high quality concrete.

Model HZS25 HZS35 HZS50 HZS75
Capacity (m3/h) 25 35 50 75
Mixing Time (s) 60 60 60 60
Max Aggregate Size (mm) 40/60 40/60 60/80 60/80
Discharging Height (mm) 3800 3800 4000 4000
Total Power (kW) 60 70 80 90
Total Weight (Ton) 25 30 50 54
Total Dimensions (m) 15×8×12 15.2×8.5×15.4 18.2×10×19.4 18×10×19.4
